Product Details:
|
| Output Voltage (Kv): | 150-250 | Inpu T (KW ): | 2.5 |
|---|---|---|---|
| Focus Spot (mm): | 2.0*2.0 | Beam Angle: | 40+5° |
| High Light: | 250kv portable x ray flaw detector,XXQ-2505 portable x ray flaw detector,XXQ-2505 x ray flaw detector |
||
Portable Directional Radiation X-ray Flaw Detector Glass X-ray Tube Max Penetration 39mm 250kv XXQ-2505
Detailed Product Description
Directional radiation portable X-ray flaw detector XXQ-2505 max penetration 39mm 250kv (Glass x-ray tube) XXQ series are suitable for the material directional of thin iron plate, aluminum, rubber and so on, may get very good picture.
Feature:
●Checking the software and hardware itself after start the machine
●Excellent anti-jamming performance, which can adapt for field operation without power supply, because of the motor supports
●Can adjust exposure parameters with keys ( easy operation.)
●Has the function of Delay time opening HV. Convenient for operator keep away from dangerous field
●Can adjust high voltage slowly for protecting X-ray generator
●Automatically controlling according to 1:1 working and rest operating way, the longest continuous exposure period is 5 minutes.
●Including complete protecting system: over KV, over KV, low mA, over mA, over temperature and optical-sound alarming
●Convenient for repairing and maintenance
●Much more Substance for structure designing, much more convenient for local operation
●Time can be changed for±0.3 according to the power supply net to make the exposure more precise
Specification:
| XXQ-250 5 | Output voltage (Kv) | Inpu t (KW ) | Focus spot (mm) | Beam angle | Max penetratio n (mm) | Weight (KG) | Dimensions (mm) | ||
| 150-250 | 2.5 | 2.0*2.0 | 40+5° | 39 | Generat or | Controll er | Generator | Generator | |
| 33.5 | 9.4 | 320x320x7 40 | 350x290x1 60 | ||||||
Standard Delivery:
| Directional glass X-ray tube | 1 Pcs | |
| Generator | 1 Set | |
| High voltage joins cable | 1 Pcs | 25 Meters |
| Controller | 1 Set | |
| Power cable | 1 Pcs | 10 Meters |
| Grounding cable | 1 Pcs | 5 Meters |
| Accessories | 1 Set | |
| (Including: alarm lamp, 1 Pcs; lead letter, 1 box; Film dark cassettes 5 pcs; intensifying screen 5 pcs; Wire penetrameter (IQI) 1 set; fuse1 pc | ||
