8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min

8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min
8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min

Large Image :  8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min

Product Details:
Place of Origin: China
Brand Name: HUATEC
Certification: CE ISO
Model Number: HDL-380
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 500 Set per month
Contact Now

8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min

Description
Film Release Method: Front/back Film Release Film Development Speed: 40-240s Adjustable
Moving Speed: 950mm/min (running Time: 40 Seconds) Water Consumption: 2 L/min During Film Operation
Heating Element: PTC Heating Element
Highlight:

Adjustable Speed Film Dryer

,

8 channel Film Dryer

HDL-380 Film dryer with 8 air flow channels



8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 0 8-channel Air Flow Industry Film Dryer With Adjustable Development Speed Of 40-240s And Low Water Consumption Of 2 L/min 1



Technical parameters and specifications



● Drying process: → → Water washing → → Drying → →

● Film release method: front/back film release

● Film development speed: 40-240s adjustable

● Sheet feeding width: 360mm

● Moving speed: 950mm/min (running time: 40 seconds)

● Dry tablet quantity: 80X360mm (4 "X14") film 600 sheets per hour (dry film speed 40s)

● Power supply: 200-240V. 50/60Hz 5A

● Water consumption: 2 l/min during film operation

● Volume: 560mmX480mx545 (length x width x height)

● Add the function of chip induction

● 8 air flow channels, Improved air duct, higher drying efficiency

● Roller shaft: DuPont foamed uranium is used to ensure that it will not harden within 5 years

● Shell: engineering PVC plastic

● Heating element: PTC heating element

● Temperature control mode: constant temperature control with solid-state relay

● Optional parts: water washing circulating device, which aims at no tap water, poor water quality or frequent water stoppage at the use site
