Handheld Charging Dtyle LED-UV Lamp With UV and White Light Dual Function

Large Image : Handheld Charging Dtyle LED-UV Lamp With UV and White Light Dual Function

Product Details:

Place of Origin:	China
Brand Name:	HUATEC
Certification:	ISO,CE
Model Number:	DG-9W
Document:	DG-9W.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Packaging Details:	in carton box
Delivery Time:	5~7 days after payment
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	100 pcs per month

Contact Now

Handheld Charging Dtyle LED-UV Lamp With UV and White Light Dual Function

Description

UV(Light)-FLUX Indoor Temperature 25℃:	8000uW/cm - Light-MAX1500LUX	Grading Feature:	Centre Grading
Battery Capacity:	5800mA/H 12.6V	White Light In Black Light:	>30LUX
Battery Life (cumulative Time):	UV LED 5-6H Or Light 16H	Lamp Life:	20000H
Highlight:	Handheld LED-UV lamp with dual function , UV and white light LED lamp , Magnetic particle testing UV lamp

Handheld Charging Dtyle LED-UV Lamp With UV and White Light Dual Function

Characteristic:

Irradiance>8000uw/cm2

Internal batteries

Pre-alert and protection of low power

Light source life 30000H

Parameters:

Item	parameter
Style	handheld
Quantity of lamp head	UV head:3pcs, white light head:1pc
UV(Light)-FLUX Indoor temperature 25℃	UV-MAX8000uW/cm2, Light-MAX1500LUX
Grading feature	Centre grading
Irradiation area at depth of 380mm:(≥1000uw/cm²)	Φ200mm
Wavelength accuracy	±5nm
Power supply	AC100-240V 50/60Hz
Power	UV LED-9VA Light-3VA
Wave length	365nm±3nm(UVA) (Indoor temperature 25℃)
Outline dimension	203mm(W)110MM(D)220mm(H)
Weight	1kgs
Battery capacity	5800mA/H 12.6V
Charging time	4-5H
Battery cumulative time	UV LED 5-6H or Light 16H

Feature:

9VA power saving of power consumption

30000H life expectancy of light source

High quality light source UVLED

0 UV-B contained

Battery endurance 5-6hrs

Pre-alert and protection of low power

Weight of 1kg only including batteries

Build in battery, no wiring outside

Three minute delay(power saving)//constand lighting,mode can be switched

Quartz and optical glass module, not PMMA material, excellent weather resistance

Continuous operation and external surface temperature rises less than 5 Celsius

No need to preheat, instant to reach 100% power

With UV and white light dual function, one hand switch.
