Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution

Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution
Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution

Large Image :  Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution

Product Details:
Place of Origin: Beijing
Brand Name: HUATEC
Certification: CE ISO
Model Number: HV-10MDX
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Plywood Airplane standard package
Delivery Time: 4 working days
Payment Terms: Western Union, L/C, T/T
Supply Ability: 500 per months

Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution

Description
Material: Steel Test Force: 0.3Kgf (2.94N)、0.5Kgf (4.90N)、1.0 Kgf (9.8N)、2.0Kgf(19.6N)、3.0Kgf(29.4N)、5.0Kgf(49.0N)、10.0Kgf(98.0N)
Standard: GB/T4340,ASTM E92 Test Resolution: 0.01µm
Range: 8~2900HV Testing Process: Automatic (loading, Dwelling , Unloading)
Test Microscope Magnification: 100X、200X(Both Of Them Can Be Used For Testing) Force Dwell Time: 0~60s
Maximum Height Of Specimen: 180mm Distance From The Center To The Outer Wall Of The Indenter: 160mm
Dimension: 600*190*620mm Power: AC220V+5%,50-60Hz
Conversion Scales: HRA、HRB、HRC、HRD、HRF、HV、HK、HBW、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T Data Output: LCD Display,saved In EXCEL Format On A Usb Stick
High Light:

metal hardness tester

,

ultrasonic hardness tester

HV-10MDX Auto Turret Touch Screen Digital Vickers Hardness Tester Automatic (loading, Dwelling , unloadin



Main features:

Electronic loading, high accuracy sensor,with special closed-loop control system, each force is automatically compensated.

Touch screen, simple operation of menu structure.

Eyepiece structure with digital encoder, measure D1, D2 value, LCD display hardness value and D1, D2 value directly.

Auto-turret,the indenter and the objective lens are automatically switched to each other, and the test point is automatically positioned accurately, loaded and unloaded.

The hardness values of brinell, rockwell and vickers can be converted.

It can be calibrated according to standard hardness block or length scale.

Test force can be automatically corrected by standard dynamometer.

All data is saved in EXCEL format on a usb stick

Double language setting, convenient for users to choose.



Technical specification:

Model HV-10MDX
Test force 0.3Kgf (2.94N),0.5Kgf (4.90N),1.0 Kgf (9.8N),2.0Kgf(19.6N),3.0Kgf(29.4N),5.0Kgf(49.0N),10.0Kgf(98.0N),
Carried standard GB/T4340,ASTM E92
Min measurement unit 0.01µm
Data output LCD display,saved in EXCEL format on a usb stick
Conversion scale HRA,HRB,HRC,HRD,HRF,HV,HK,HBW,HR15N,HR30N,HR45N,HR15T,HR30T,HR45T
Hardness range 8~2900HV
Test force loading method Automatic(laoding,dwell,unloading)
Eyepiece magnification 100X(testing),200X(testing)
Dwell time 1~99s
Max height of specimen 180mm
Distance from indenter to the wall 160mm
Dimension 580*190*700mm
Weight about 55Kg
Power supply AC220V+5%,50-60Hz


Operation interface:



Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution 0Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution 1Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution 2Automatic Loading Hardness Measuring Instrument 0.01µM Test Resolution 3



Standard accessories

Item Quantity Item Quantity
HV-1000-10X eyepiece 1 Large, medium, V sharped test table Each 1
Vickers test block 2 Fuse (2A) 2
Power cord 1 Dust bag 1
U disk 1 Touch pen 1
Certificate, warranty card 1 Manual 1
Wrench 1 Regulating screw 4
