Product Details:
|
| Festing Range:: | 0~20HW | Accuracy: | 0.5HW |
|---|---|---|---|
| Eqnivaient Range:: | See Table 1 | Weight:: | 0.5kg |
| High Light: | 20HW Webster Hardness Tester,High Accuracy Webster Hardness Tester,HUATEC Webster Hardness Tester |
||
High Accuracy, Portable Stable 0~20HW Webster Hardness Tester W Series
Main Technical Parameters
Festing Range:0~20HW
Accuracy: 0.5 HW
Eqnivaient range:See Table 1
Weight: 0.5 kg
Model Guide
Operating Method
Put the specimen between the anvil and the indenter and press down the handle until thebottom is felt. At the time the dial indicator will point at a reading which is the hardness valueobtained. Excessive pressure beyond this limit will not damage the tester, but it is unnecessary.Hold tight the handle when reading the value. Any torsion or movement will make the reading incorrect during the test.
Standard Package
| 1 |
Tester |
| 1 |
standard hardness block (attached with measurement and inspection report) |
| 1 | spare indenter |
| 1 | wrench |
| 1 | small screwdriver |
| 1 | instruction manual |
| 1 | carrying case |
Optional Accessories
spare indenter
standard hardness block
spare dial glass
