Integral DUAL OLED Surface Roughness Tester SRT5030

Large Image : Integral DUAL OLED Surface Roughness Tester SRT5030

Product Details:

Place of Origin:	China
Brand Name:	HUATEC
Certification:	ISO,CE
Model Number:	SRT5030
Document:	Integral Surface Roughness ...30.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Packaging Details:	in carton
Delivery Time:	5-7 days after payment
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	50 sets per month

Contact Now

Integral DUAL OLED Surface Roughness Tester SRT5030

Description

Product Name:	Roughness Tester	Light Weight:	150g
Optional Parameter:	Ra, Rz, Rq, Rt	Display Accuracy:	0.01μm
Battery:	3.7V Lithium Rechargeable Battery	Dimensions In Mm:	110×81×32
Highlight:	Dual OLED surface roughness tester , SRT5030 roughness testing equipment , Non-destructive surface roughness meter

Integral DUAL OLED Surface Roughness Tester SRT5030

Features

Dual OLED displays to suit your applications;

2 start keys ( the left key & the right key) to satisfy the different using habits;

Mobile app compatible to get the higher accuracy, convenient to be used in a small space

ARM processor to offer higher speed, low power consumption and fast accurate measurement.

Light weight of 150g, easy & convenient to use.

Main Technical Specifications
Optional Parameter	Ra, Rz, Rq, Rt
Measuring Range(μm)	Ra, Rq: 0.05 ~ 10.0; Rz, Rt: 0.1 ~ 50
Sampling Length(mm)	0.25/ 0.80/ 2.5
Evaluation Length(mm)	1.25/ 4.0/ 5.0
Running Length(mm)	6
Display Accuracy	0.01μm
Display Deviation	±(7-10)%
Display Repeatability	＜12%
Stylus Radius	10 μm±1 μm
Static Contact Force	≤ 0.016N
Force Change Rate	≤ 800N/m
Sensor Lead Pressure	≤ 0.5N
Battery	3.7V Lithium Rechargeable battery
Dimensions in mm	110×81×32
Weight	150g

Standard Delivery

Main Unit	1 pc
calibration block	1pc
Power adapter	1pc
USB cable	1 pc
User Manual	1 pc
Calibration certificate	1 pc

Integral DUAL OLED Surface Roughness Tester SRT5030
