Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter

Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter
Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter
Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter

Large Image :  Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter

Product Details:
Place of Origin: China
Brand Name: HUATEC
Certification: ISO, CE, GOST
Model Number: HG908
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Standard export package
Delivery Time: 1-4working days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 500Pcs

Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter

Description
Battery: 9V 6F22/Rechargeable, 25/10 Hours Of Continuous Operation. HG908: Separate Accelerometer With Magnetic Mount & Probe, Long Needle Probe
Pickup: Accelerometer With Handheld Probe And/or Magnetic Mount Dimensions: 13×6×2.3 Cm; Weight: 200 G
High Light:

Hg-908 Portable Vibration Meter

,

automatic shutdown portable vibration meter

,

double probe portable vibration meter

Portable Automatic Shutdown Double Probe Hand-Held Vibration Meter HG-908



Features:

Small size, transducer included,

True RMS measurement.

Measuring parameters: vibration velocity, displacement,acceleration and high-frequency acceleration Battery powered,

Accelerometer may be integrated or external cable connected.

One button control both power and measurement.Very easy to use.

3 1/2 LCD digital display, sampling per second.

Holding function. Automatic power off.

Suitable for monitoring machinery vibration caused by imbalance,misalignment, gear & bearing faults and etc.

Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter 0Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter 1Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter 2Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter 3Automatic Shutdown Double Probe Hg-908 Portable Vibration Meter 4

Specifications:

Testing ranges:

Displacement 1—1999 m m (or 200 mil) Eq. peak-peak

Velocity 0.1—199.9 mm/s (or 20 in/s) true RMS

Acceleration 0.1—199.9 m/s2 (or 20 g) Eq. Peak

High Frequency Acceleration: 0.1—199.9 m/s2 (or 20 g) Eq. Peak

Overall accuracy: ±5%

Temperature range: 0 - 50°C

Frequency response:

Displacement 10-1000Hz

Velocity 10-1000Hz

Acceleration 10-1000Hz (908B) 105000Hz (908)

High Frequency Acceleration: 1000-5000Hz 10%



Configuration:



HG908: Separate accelerometer with magnetic mount & probe, long needle probe

Battery: 9V 6F22/Rechargeable, 25/10 hours of continuous operation.

Pickup: Accelerometer with handheld probe and/or magnetic mount

Dimensions: 13×6×2.3 cm; Weight: 200 g

Optional Intrinsically safe version with internal accelerometer



HG908 Separate accelerometer with magnetic mount & probe, long needle probe
Battery 9V 6F22/Rechargeable, 25/10 hours of continuous operation.
Dimensions 13×6×2.3 cm; Weight: 200 g
Pickup Accelerometer with handheld probe and/or magnetic mount



1.Preparation



1). Check the voltage of the battery:

Press M<easure> key, observe the display on the screen. If there is an arrow on the top left corner, you need to replace the battery with a new one.

2). Set-up probe

HG908 with outside accelerometer has 1 probe and 1 magnetic mount. When changing, take hold of the accelerometer to avoid rotation and damage of the cable.



2.Measurement



1). Select the measure parameters:

HG908 has 4 vibration parameters. They are:

a) Displacement(unit: mm=1/1000 mm): Equivalent peak-peak value

b) Velocity (unit: mm/s) : True RMS Value;

c) Acceleration (unit: m/s2): Equivalent peak

d) High Frequency Acceleration (unit: m/s2): Equivalent peak

2). Functions of the M<easure> key:

a).Key press: Power on and begin measuring;

b).Key release: Hold the last measured value for twenty seconds and then power off automatically.

3). Stick the probe to the measured object (the pressure should be about 0.5-1 kg.)



3. Notes

1). Avoid intense impact, high temperature and immersed in water.
2). Keep the sensor plug clean and dry, and use it carefully.
3). Install the battery:
a) Open the small back cover of battery cabinet (2 screws at the end far away from the sensor at backside, see figure);
B) Place a battery (6F22, 9V) correctly according to the polarity;
C) Close the back cover and screw the tightly;
D) If it has been put aside long-term, please take out the battery
To avoid the battery liquid;
4) If the sensor has been used for over one year,
please re-calibrate the sensor and the meter together to ensure the precision.



4. Specifications

1). Measurement condition:
Temperature: 0oC -45oC, Humidity&lt;
85%, Non-causticity environment,
without strong electric-magnetic field & strong impact. It can be used in industry location by controlling the EMC
environment throughout installation and/or usage.
2). Amplitude Ranges:
Below 1  1999  m peak - peak (*)
True RMS Velocity  0.1 199.9 mm/s
Acceleration and High Frequency Acceleration:
 0.1 199.9 m/s2 peak (*)
*Note: peak-peak and peak are equivalent value means: peak-peak=2.828*RMS while peak=1.414*RMS
3). Accuracy:  5% of display digit 2
Noise Level (without input): ACC&lt;
0.3 m/s2, VEL&lt;
0.5 mm/s, Disp&lt;
3  m
Frequency response accuracy:  5%;
( 10% for ACC 4.5 kHz - 10 kHz)
Non - linearity:  5%
4). Sensor type: Shear type Piezoelectric Accelerometer
5). Frequency Response: 101000Hz (Inside Accelerometer)
105000Hz (Outside Accelerometer, Page on Model)
High Frequency Acceleration: 1000-5000Hz 10%
6). Battery: 9V 6F22, 25 hours of continuous operation.
7). The Configuration:
Standard: Outside accelerometer with magnetic mount and probe
Optional: Inside Accelerometer with 2 handheld probes
8). Dimensions: 13  6  2.3 cm;
Weight: 250 g.
