HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard

HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard
HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard
HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard

Large Image :  HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard

Product Details:
Place of Origin: China
Brand Name: HUATEC
Model Number: HT-6510P
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 80~140 per set
Packaging Details: in High quality carton
Delivery Time: 3-7 days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 100 sets per month

HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard

Description
Product Name: Pencil Hardness Tester Model: HT-6510P
Load Weight: 500g/750g/1000g Measurement Angle: 45°
Scratch Speed: About 1mm/s.
High Light:

coating pen type hardness tester

,

astm d3363-00 pen type hardness tester

,

pen type hardness testing machine

500g/750g/1000g weight Pencil Hardness Tester HT-6510P



Product details

Coating hardness is the necessary measurement for the performance of coatings. This instrument applied the Pencil Scratch Method. It is a fast and economical way to determine the film hardness using the drawing lead core or the pencil core. The pencil scratch method for coating hardness testing is a common method in the world since the 1980s. In China, this test method has also been promoted to the coating research and industrial production. The instrument can be used both in laboratory and on site. Referenced standard, Coating Hardness Pencil Test Method Standard Test Method for Determination of Coating Hardness by Pencil Test Method General Method for Preparing The Film 2.

Standard GB/T 6739-2006
  ASTM D3363-00
  GB/T 1727-92



Specification and principles

Load Weight 1000g /750g /500g Measurement Angle (Between Pencil and Measured Surface), 45° Three Touch Points (Two Wheels, a Pencil Core). Scratch Speed: about 1mm/s.



Usage

The instrument applies mechanical measurement. Keep three point touch the coating (two wheel, a pencil core), and a 45 degree angle between pencil and test surface. Push the instrument sliding, pencil draws the corresponding track in the coating. In the change of different pencil marks, the hardness value of the film can be determined.

HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard 0





HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard 1



Structure

HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard 2

HT-6510P Coating Pen Type Hardness Tester GB/T 6739-2006 ASTM D3363-00 Standard 3

1 - Horizontal Mark

2 - Pencil

3 - Wheel

4 - Coating

5 - Base Material

6 - Weights

7 - Screw

8 - Moving Direction

9 - Pencil Core



Standard Configuration

Pencil Hardness Tester...............1

1000g Weight............................1

750g Weight..............................1

500g Weight.............................1

Pencils (6B-6H).......................13

Eraser.......................................1

Knife........................................1

Horizontal Pad Block.................1

Sandpaper.................................1
