HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time

HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time
HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time

Large Image :  HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time

Product Details:
Place of Origin: China
Brand Name: HUATEC
Certification: ISO, CE, GOST
Model Number: HRD-4
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Contact Now

HRD-4 Wristwatch-style Personal Dosimeter with Alarm Function IP67 Protection and 100 Hours Continuous Working Time

Description
Cumulative Dose Error: ＜±15%（137Cs）
Highlight:

Alarm Function Personal Dosimeter

,

IP67 Protection Wristwatch Dosimeter

,

100 Hours Continuous Working Time Radiation Dosimeter

HRD-4 Wristwatch-style Personal Dosimeter
Function Overview

The HRD-4 wearable (wristwatch-style) personal dosimeter is designed for measuring personal dose equivalent caused by X and γ radiation. This device is particularly suitable for medical applications in interventional radiotherapy.

Controlled by a low-power single-chip microcomputer, this dosimeter provides comprehensive functionality including:

  • LCD drive display
  • Measurement data storage
  • Parameter setting capabilities
  • Detector fault alarm
  • Battery voltage detection
  • Over-threshold sound and light alarm
  • Charging functionality

This versatile dosimeter can be applied to radiation dose equivalent measurement in various scenarios including radioactive medical treatment, industrial non-destructive testing, radioactive isotope application, occupational disease prevention, military units, nuclear power plants, and surrounding areas of radioactive workplaces.

Technical Specifications
Parameter Specification
Measuring Range Dose equivalent rate: 0.10 μSv/h - 50 mSv/h
(Customizable non-standard range available)
Cumulative Dose Equivalent 0.0 μSv - 9999 mSv
Cumulative Dose Equivalent Response Error < ±15% (137Cs)
Energy Response Range 50 keV - 1.3 MeV
Alarm Function Continuously adjustable alarm threshold
Data Transmission Measurement data transmission to computer via data cable
Protection Grade IP67
Working Time 100 hours continuous operation after full charge
Temperature & Humidity Range -10℃ to +50℃, 0-95% RH (Error ≤ ±10%)
Overall Dimensions Diameter: 47.5mm, Thickness: 20mm
