Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables

Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables
Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables
Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables

Large Image :  Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables

Product Details:
Place of Origin: China
Brand Name: HUATEC
Certification: ISO, CE, GOST
Model Number: probe block
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Standard export package
Delivery Time: 1-4working days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 500Pcs

Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables

Description
Product Name: UT Block UT Probe Warranty: 12 Month
Type: Ultrasonic Flaw Detector Weight: 1kg
High Light:

ultrasonic flaw detector ndt parts

,

ultrasonic flaw detector connector ndt parts

,

ultrasonic flaw detector cables ndt parts

Voltage Stability, High Temperature Resistance Ultrasonic Flaw Detector Connector, Adapter, Socket And Cables



BNC-BNC, BNC-LEMO, LEMO-LEMO all kinds of cables available.

BNC -BNC and BNC-MD Cables have heavy duty injection molded rubber strain reliefs on both ends for greater durability.

RG-174 highly flexible coaxial cable and RG-58 heav duty cables are offered

20um thick gold plating for corrosion resistance and efficiency.

Special cable lengths and custom cables are available.

Qualtity discounts may also be available for combinations of cable types

Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables 0Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables 1Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables 2



Ultrasonic Flaw Detector Ndt Parts Connector Adapter Socket And Cables 3

DA231 information:



name length material
DA231 Dual cable 1.5 meters RG174
1.8 meters
2 meters Any other ultrasonic probe cables can be done
Ultrasonic Transducer

Probe type Designation Angle Transducer element size [mm] Frequency [MHz]



angle probe

HFD 9x8-2M-35 35° 8x9 2 MHz
HFD 9x8-2M-45 45° 8x9 2 MHz
HFD 9x8-2M-60 60° 8x9 2 MHz
HFD 9x8-2M-70 70° 8x9 2 MHz
HFD 9x8-2M-80 80° 8x9 2 MHz
HFD 9x8-4M-35 35° 8x9 4 MHz
HFD 9x8-4M-45 45° 8x9 4 MHz
HFD 9x8-4M-60 60° 8x9 4 MHz
HFD 9x8-4M-70 70° 8x9 4 MHz
HFD 9x8-4M-80 80° 8x9 4 MHz



angle probe HFD 22x20-2M-35 35° 20x22 2 MHz
HFD 22x20-2M-45 45° 20x22 2 MHz
HFD 22x20-2M-60 60° 20x22 2 MHz
HFD 22x20-2M-70 70° 20x22 2 MHz
HFD 22x20-2M-80 80° 20x22 2 MHz
HFD 22x20-4M-35 35° 20x22 4 MHz
HFD 22x20-4M-45 45° 20x22 4 MHz
HFD 22x20-4M-60 60° 20x22 4 MHz
HFD 22x20-4M-70 70° 20x22 4 MHz
HFD 22x20-4M-80 80° 20x22 4 MHz





Probe type Designation Transducer element* diameter[mm] Frequency[MHz]

Standard straight probe



HFD 10-2M Ø 10 2 MHz
HFD 10-4M Ø 10 4 MHz
HFD 10-6M Ø 10 6 MHz
HFD 20-2M Ø 20 2 MHz
HFD 20-4M Ø 20 4 MHz
HFD 20-6M Ø 20 6 MHz



Probe type Designation Transducer element* diameter[mm] Frequency[MHz]

Dual straight probe
PQ 2/10-2M Ø 10 2 MHz
PQ 2/10-4M Ø 10 4 MHz
PQ 2/10-6M Ø 10 6 MHz
PQ 2/20-2M Ø 20 2 MHz
PQ 2/20-4M Ø 20 4 MHz
PQ 2/20-6M Ø 20 6 MHz



Probe type Designation Angle Transducer element* diameter[mm] Frequency[MHz]

Dual angle probe
HFD 13x8-2M-60 60° 8x13 2 MHz
HFD 13x8-2M-70 70° 8x13 2 MHz
HFD 20x10-2M-60 60° 10x20 2 MHz
HFD 20x10-2M-70 70° 10x20 2 MHz
HFD 13x8-5M-60 60° 8x13 5 MHz
HFD 13x8-5M-70 70°



8x13

5 MHz

Note:

1.Other special probes are available such as Angle beam probe with pour water, probe for variable angle, probe for locomotive piston, beam TR probe with pour water, probe for railcar axle, probe for demarcate echo, cleanout machine transducer etc.

2.We offer all kinds of probe with customer request.

Testing Curve Report for Transducers (optional by order)
