Product Details:
|
| Measurement Range: | 1.5-240.0mm | Receiving Gain: | ≤ 100dB |
|---|---|---|---|
| Working Temperature: | - 150 ℃~+800 ℃ | Maximum Lifting Distance: | 4mm |
| High Light: | Electromagnetic ultrasonic thickness gauge,4mm ultrasonic thickness gauge,Electromagnetic ultrasonic thickness tester |
||
Electromagnetic ultrasonic thickness gauge TG-14
Electromagnetic ultrasonic thickness gauge is an ultra small, non-contact thickness measuring instrument without acoustic coupling agent. It can measure the thickness of metal or magnetic conductive materials.
| Measurement range | 1.5-240.0mm,the maximum value of the measurement range is affected by the properties of the measured material, sound attenuation coefficient, surface conditions and other factors |
| Error range of measuring equipment | hen the thickness of workpiece is less than 10mm, the error is 0.05mm; when the thickness is more than 10mm, the error is + (0.01 + H / 200) mm (H is the thickness of workpiece) |
| Receiving gain | ≤ 100dB |
| Working temperature range of high temperature probe | low carbon steel (or other ferromagnetic steel): - 150 ℃~+800 ℃; Austenitic stainless steel (or other non ferromagnetic materials): - 150 ℃~+150 ℃ |
| Normal temperature probe | ≤ 80 ℃, 4MHz, mainly used to detect fine-grained materials, such as low carbon steel, aluminum, etc., |
| High temperature probe | ≤ 800 ℃, 4MHz, mainly used to measure ferromagnetic fine-grained materials, such as low carbon steel |
| Maximum lifting distance | 4mm (the actual lifting distance is related to the material property and temperature). Anti rust film, salt deposit or any other insulating coating (paint, varnish, enamel, plastic, etc.) can be used as the operating gap |
| Sonic sound speed adjustment range | 1000-9999 m/s |
| Power supply | built in lithium battery, working time not less than 5 hours |
