HUA-100 Digital Portable X Ray Film Transmission Density Densitometer

HUA-100 Digital Portable X Ray Film Transmission Density Densitometer
HUA-100 Digital Portable X Ray Film Transmission Density Densitometer HUA-100 Digital Portable X Ray Film Transmission Density Densitometer

Large Image :  HUA-100 Digital Portable X Ray Film Transmission Density Densitometer

Product Details:
Place of Origin: China
Brand Name: HUATEC
Certification: CE
Model Number: HUA-100
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: USD1207/set - USD1365/set
Packaging Details: Carton packing box
Delivery Time: 7-10 working days after receipt of your payment
Payment Terms: T/T,Paypal
Supply Ability: 10sets/Month
Contact Now

HUA-100 Digital Portable X Ray Film Transmission Density Densitometer

Description
Range: 650Cd/m - 320 000 Cd/m Density: 4.50D - 5.00D
Accuracy: ±0.03D Resolution: 0.01D
Repeatability: 0.02D Power Supply: (AA/1.5V)x2-Alkaline Battery
Highlight:

X Ray Film Transmission Density Densitometer

,

Digital Density Densitometer

,

Portable Density Densitometer

HUA-100 Digital Portable X-ray Film Transmission Density Densitometer



Instruction:

The HUA-100 is a robust, easy to use, portable densitometer for measuring the transmission density of x-ray film. The unit has been designed for using in one-site mobile darkrooms, laboratories and offices. The HUA-100, with a extremely wide light range of between 650Cd/m and 320 000 Cd/m , has a density measuring range from 0D to 4.5D with an accuracy to within ±0.03D over an aperture of 3mm in diameter.

The operator simply places the film on the viewer (emulsion side up), places the probe on the film where the reading is required and the reading will appear on the 4 digit LCD screen with white light illuminated display. And a low battery warning indicator is provided on the digital display.



Technical Specifications:

Range: 650Cd/m - 320 000 Cd/m
Density: 4.50D - 5.00D
We strongly suggest HUA-100 work with HFV series LED viewers. With HFV-2008, the maximum density of HUA-100 would be > 5.00D.
Optical Aperture: 3mm diameter
Probe Temperature compensated
Display: 4 digit LCD
Accuracy: ±0.03D
Resolution: 0.01D
Repeatability: 0.02D
Detector: Silicon photodiode
Power supply: (AA/1.5V)x2-Alkaline Battery
Battery life:

1200 hours

(Continuous duty, without illuminated)
Dimensions: 160mm x 65mm x 23mm
Weight: 760g



HUA-100 Digital Portable X Ray Film Transmission Density Densitometer 0HUA-100 Digital Portable X Ray Film Transmission Density Densitometer 1HUA-100 Digital Portable X Ray Film Transmission Density Densitometer 2
