Stainless Steel 44 Ml Newton Liquid Viscosity Zahn Cup For Professional Viscosity Testing

Large Image : Stainless Steel 44 Ml Newton Liquid Viscosity Zahn Cup For Professional Viscosity Testing

Product Details:

Place of Origin:	China
Brand Name:	HUATEC
Certification:	CE
Model Number:	Zahn Cup

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	USD460-USD520/SET
Packaging Details:	Outer carton packaging
Delivery Time:	7-10 working days after receipt of your payment
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10 Sets/Month

Contact Now

Stainless Steel 44 Ml Newton Liquid Viscosity Zahn Cup For Professional Viscosity Testing

Description

Standard:

ASTM D4212-93

Material:

Stainless Steel

Size:

44 Ml

Highlight:

Professional Viscosity Zahn Cup

Stainless Steel Viscosity Zahn Cup

44 ml Viscosity Zahn Cup

Newton Liquid Viscosity Zahn Cup

Introduction:

1107 Zahn Cup is designed according to the standard of ASTM D4212-93. Zahn Cup, it can be used to measure the viscosity of Newtonian or near-Newtonian liquids.Adjustable in anywhere such as the workshop, factory and lab etc. And quickly measure the viscosity of liquids. This Flow Cup is widely used in ink and printing industry.

Technical Specification:

◆Material:Stainless steel
◆Size: 44 ml

Order Information:

Order No.	Orifice(mm)	Viscosity Range(cSt)	Flow Time(Sec)
1107/1	1.92	5 - 60	35-80
1107/2	2.70	20 -250	20-80
1107/3	3.85	100 -800	20-80
1107/4	4.40	200 -1200	20-80
1107/5	5.40	400 -1800	20-80

Stainless Steel 44 Ml Newton Liquid Viscosity Zahn Cup For Professional Viscosity Testing 0
