HPT50 Concrete Cover Thickness Tester for Reinforcement Position

Large Image : HPT50 Concrete Cover Thickness Tester for Reinforcement Position

Product Details:

Place of Origin:	China
Brand Name:	HUATEC
Certification:	CE
Model Number:	HPT50

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	USD920/set - USD1040/set
Packaging Details:	Carton packing box
Delivery Time:	7-10 working days after receipt of your payment
Payment Terms:	T/T,Paypal
Supply Ability:	10sets/Month

Contact Now

HPT50 Concrete Cover Thickness Tester for Reinforcement Position

Description

Bar Diameter Application Range(mm):

Φ6 – Φ50

Maximum Value Permissible Error Of Bar Diameter:

≤±1

First Measuring Range (mm):

6 - 90

Second Measuring Range (mm):

7-180

Highlight:

concrete cover thickness tester

reinforcement position detector

non-destructive testing equipment

HPT50 Reinforcement Position Concrete Cover Thickness Tester

Product Specifications

Attribute	Value
Bar diameter application range (mm)	Φ6 – Φ50
Maximum value permissible error of Bar diameter	≤±1
First measuring range (mm)	6 - 90
Second measuring range (mm)	7-180

Key Features

Investigation depth could reach 180mm
Single comprehensive probe - no need to replace during test
Back-lit screen allows normal use under low light conditions
Complete machine software with automatic report printing when connected to computer

Technical Specifications

Measurement Range	Maximum Error
6 - 59mm (First range) 7 - 79mm (Second range)	≤±1
60 - 69mm (First range) 80 - 119mm (Second range)	≤±2
70 - 90mm (First range) 120 - 180mm (Second range)	≤±4

Standard Delivery

Main unit with software
USB connecting cable
Power charger
Carborundum stone
Instruction manual
Warranty card

Optional Accessories

Printer
Power Charger for printer (9V/2V)

Work Environment Conditions

No strong alternating electromagnetic field
No corrosive gas in the air
Avoid larger vibration and impact
Avoid direct sunlight on LCD panel

Product Applications

Testing concrete cover thickness
Testing concrete member internal reinforcement position, rebar spacing, and reinforcement position distribution
Estimation of bar diameter
Detection of cable and plumbing pipes
