50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision

50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision

Large Image :  50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision

Product Details:
Place of Origin: Beijing, China
Brand Name: HUATEC
Certification: CE,ISO
Model Number: HD-105A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: abs case+carton
Delivery Time: 5-8 work days
Payment Terms: T/T,Western Union
Contact Now

50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision

Description
Thickness Range: 0.1～35mm Voltage Precision: ±（0.1kv+3%）
Test Voltage Range: 1KV～50KV Battery: 12V 4400mA
Working Time: ≥12 Hours(Max Voltage)
Highlight:

50KV Holiday Detector

,

0.1～35mm Thickness Range Coating Quality Detector

,

±(0.1kv+3%) Voltage Precision Pinhole Detector

50KV Intelligence Pulsed High Voltage Protecting Coating Quality Detector HD-105A
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 0 50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 1
About HD-105A
The HD-105A holiday detector is an intelligent pulsed high voltage protecting coating quality detector. It features an anti-interference intelligent chip, anti-interference LED screen, and advanced digital control circuitry for precise high voltage output (±0.1KV+3% reading). The device automatically adjusts voltage according to coating thickness and operates on lithium battery power for field use.
Operating Principle
When the high voltage probe passes over non-conductive coating, spark discharge occurs if the coating is too thin or has leaks/pinholes. The detector simultaneously records the number of leaks detected.
Applications
With its advanced, stable, and reliable design, the HD-105A is widely used in chemical, oil, rubber, and enamel industries for detecting metal anti-corrosion coating quality.
Technical Specifications
Parameter Specification
Test voltage range 1KV～50KV
Thickness range 0.1～35mm
High voltage output Pulse
Voltage display 3 digit
Resolution 0.1KV
Voltage precision ±(0.1kv+3%)
Max leak record 999 maximum
Way of alarming Headphone buzzer and light
Shutdown Auto and Manual
Display 128*64 LED screen with backlight
Power ≤6W
Size 240mm*165mm*85mm
Battery 12V 4400mA
Working time ≥12 hours (Max voltage)
Charging time ≈4.5 hours
Voltage of adapter Input AC 100-240V, Output 12.6V 1A
Probe wire Close to 1.5m
Earth lead wire 2*5m black/black
Fuse 1A
Standard Delivery
  • Detector unit - 1pc
  • Probe Handle - 1pc
  • Flat brush - 1pc
  • Fan brush - 1pc
  • Connector for brushes - 1pc
  • Fuse - 2pcs
  • Charger - 1pc
  • Carrying case - 1pc
  • Instruction manual - 1pc
  • Certificate, warranty card - 1pc each
Optional Accessories
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 2
Fan brush
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 3
Flat brush
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 4
Internal brush
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 5
Circle electrode
50KV Intelligence Pulsed High Voltage Holiday Detector with 0.1～35mm Thickness Range and ±(0.1kv+3%) Voltage Precision 6
Arc electrode
